Klüber UNIMOLY HTC METALLIC High-temperature graphite paste 600g can
Klüber UNIMOLY HTC METALLIC High-temperature graphite paste 600g can
€ 311.28 311.28 incl. VAT (261.58 excl. VAT), per piece *
Availability: shipping in 6-8 weeks
Packaging unit: 1 piece
Manufacturer: KLUBER
Country of origin: BE/0017
Customs tariff number: 34031980
Weight per piece: 680 g
Please give the recipient email address, as well as your name and email address.
The product description does not help you?
No problem. Simply fill out the form and we will answer you as soon as possible.
No problem. Simply fill out the form and we will answer you as soon as possible.
UNIMOLY HTC METALLIC High-temperature paste containing graphite and metal | N° 011055
- UNIMOLY HTC METALLIC is a high-temperature lubricating and assembly paste containing graphite and metal. It has a chemical composition of mineral oil, lithium soap and a solid lubricant mixture.
- Above a temperature of 150 °C the base oil evaporates and leaves a dry lubricating film. The paste contains no lead, nickel, sulphur, barium and halogens.
- Temperature range: -25°C to +1200°C
- Volume: 600g can
Benefits for your application
- Ensures easy disassembly even after the influence of high temperatures
- High pressure absorption capacity
- Prevents stick slip
- Meets the requirements set forth by automobile manufacturers
- Also available as spray (UNIMOLY HTC METALLIC Spray, art. No. 081047)
Applications
- UNIMOLY HTC METALLIC is suitable as a high-temperature paste for screws, nuts and bolts. The resulting dry lubricant film makes it possible to disassemble these machine elements without any problems.
- In the pressure die casting industry this paste is used for the lubrication of ejector pins, core pullers and threaded connections. In the plastic processing industry UNIMOLY HTC METALLIC is used as a lubricant for heated extruder heads and screw-on nozzles. In addition, UNIMOLY HTC METALLIC has proven effective as an assembly paste for extrusion moulding dies and as a lubricant for spring washer components.
Application notes
- NOTE: Always apply UNIMOLY HTC METALLIC in a thin layer!
- Clean the friction point with a solvent and remove all residues and separating layers, such as corrosion protection agents, to ensure optimum adhesion of UNIMOLY HTC METALLIC, then apply the paste evenly across the entire surface. In the case of machine screws make sure that the paste is also applied to the underside of the screw head.
- Only if the thread and the lower surface of the screw head are coated with the lubricant will it be possible to obtain an optimum preload force during tightening and to disassemble the parts even when they were subject to high temperatures.
Technical specifications
| Lower service temperature | 25 °C / -13 °F |
| Upper service temperature | 1200 °C / 2192 °F |
| Colour space | silver |
| Density at 20 °C | approx. 1.30 g/cm³ |
| Flow pressure of lubricating greases, DIN 51805-2, test temperature: -30 °C | <= 1 400 mbar |
| Four-ball tester, welding load, DIN 51350 pt. 04 | >= 4 000 N |
| Minimum shelf life from the date of manufacture - in a dry, frost-free place and in the unopened original container, approx. | 36 months |
Hazardous materials. The forwarding charges may be raised, if shipping to: DE, AT, NL, GB, CH, CZ, IT, ES, FI, NO, BE, IE, RO, PL, FR, PT, LU, DK, LI, GR, SE, SK, BG, SI, CA, LT, EE, LV, HR,
| Property | GTIN/EAN | MPN (Manufacturer Part Number) |
|---|---|---|
| - | - | 943150109 |
