VÖLKEL WHITE RING Machine taps DIN 371/376 Form C 39°RSP HSS-E – UNC
VÖLKEL WHITE RING Machine taps DIN 371/376 Form C 39°RSP HSS-E – UNC
€ 17.97 17.97 incl. VAT (15.10 excl. VAT), per piece *
Availability: shipping in 1-2 working days
Packaging unit: 1 piece
Manufacturer: EURAFCO
Country of origin: DE/0004
Customs tariff number:
Weight per piece: 500 g
Please give the recipient email address, as well as your name and email address.
The product description does not help you?
No problem. Simply fill out the form and we will answer you as soon as possible.
No problem. Simply fill out the form and we will answer you as soon as possible.
VOELKEL HSS-E PM WHITE RING Machine taps. The VOELKEL HSS-E machine taps with white ring are especially suitable for stainless steel (INOX), long-chipping up to 1000 N/mm² and for chrome-nickel alloys.
Technical Data
Recommended application
VAP-coating
Contents
Technical Data
- Type of thread: Unified Coarse thread ANSI B 1.1
- Standard: DIN 371 / DIN 376
- Material: HSS-E
- Tolerance: ISO 2 /6H
- Size: Nominal diameter D UNC 1/4 x 20 - 1/2 x 13
- Overall length (L1): 80 mm - 110 mm
- Thread length (L2): 13 mm - 20 mm
- Shank diameter (D2): 7 mm - 9 mm
- Drive connector: Square 5.5 mm - 7 mm
Recommended application
- Stainless steel, long chipping up to 1000 N/mm²
- Abrasive material
- Chrome-nickel alloys
- For blind holes
VAP-coating
- Improved adhesion of the coolant and Lubricant
- Reduces tearing of the lubricating filand the formation of cold welding
Contents
- 1x WHITE RING machine tap, DIN 376, HSS-E, UNC
No files available for download
| Property | GTIN/EAN | MPN (Manufacturer Part Number) |
|---|---|---|
| UNC 1/4 x 20 | 4022835369455 | 36945 |
| UNC 5/16 x 18 | 4022835369462 | 36946 |
| UNC 3/8 x 16 | 4022835369479 | 36947 |
| UNC 7/16 x 14 | 4022835369486 | 36948 |
| UNC 1/2 x 13 | 4022835369493 | 36949 |
* Price in Euro including VAT, plus forwarding charges.
In parentheses: price in Euro excluding VAT, plus forwarding charges.
Clients outside the EU as well as companies outside of Germany don't pay any VAT (excepting for shipping in Germany)!
